Technical Specification:
Typ and motor size:
Brushed 540/550/775
Current const./peak:
80A/400A
Cells:
2-4s LiPo / 5-12 Zellen NiMH
Motor Limit 540/550:
2s LiPo, 6s NiMH: > 12T or < 30000 RPM
3s LiPo, 9s NiMH: > 18T or < 20000 RPM
4s Lipo, 12s NiMH: > 24T or < 15000 RPM
When driving 2 motor, the Turns of the motors need to be increased accordingly.
BEC:
Switch Mode: 6V/4A
Input connector:
No
Output connector:
Bullet 4mm (female)
Dimension:
45.9x34.7x26.5mm
Weight:
75g
Waterproof:
Yes
Applicable:
1/8, 1/10 Rock Crawler
